| OVERVIEW | |
|---|---|
| Intended Application | Home/Office, Computer Networks |
| OUTPUT | |
| Frequency compatibility | 50 / 60 Hz |
| Output watts | 1440 |
| Circuit Breaker (amps) | 12 |
| Outlet quantity / type | 4 NEMA 5-15R |
| Transformer accommodation | Supports up to 2 large transformer plug accessories without covering remaining outlets |
| INPUT | |
| Nominal Input Voltage(s) Supported | 120V AC |
| Recommended Electrical Service | 120V (110-125V) |
| Input connection type | NEMA 5-15P input plug |
| Input plug features | Space-saving right angle input plug |
| Input cord length (ft.) | 6 |
| Input cord length (m) | 1.8 |
| Voltage compatibility (VAC) | 120 |
| Maximum Surge Amps | 135000 |
| LEDS ALARMS & SWITCHES | |
| Switches | Combination AC circuit breaker and two position red illuminated on/off power switch |
| SURGE / NOISE SUPPRESSION | |
| AC suppression joule rating | 3330 |
| AC suppression response time | NM = 0 ns. CM = |
| Protection modes | Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression |
| Clamping voltage (RMS) | 140V |
| AC suppression surge current rating | 92,000 amps (36,000 NM / 56,000 CM) |
| AC suppression components used | Metal oxide varistors, toroidal balanced chokes, ferrite rod-core inductors and VHF capacitors. |
| Safe thermal fusing | Prevents unsafe conditions during extreme extended over-voltages and catastrophic occurrences |
| UL1449 let through rating | 330V - UL Verified |
| IEEE587 Cat. A ringwave let through | Less than 35 volts |
| EMI / RFI filtering | 40-80 dB |
| Isolated filter banks | Unique isolated filter bank design offers additional filtering between each duplex pair of outlets on the strip to prevent electrical noise interference between connected loads. Includes 2 filter banks. |
| Immunity | Conforms to IEE 587 / ANSI C62.41 |
| DATALINE SURGE SUPPRESSION | |
| Telephone/DSL Protection | Yes |
| UPC Codes | |
| Unit Carton UPC# | 037332010223 |
| DATALINE SURGE SUPPRESSION | |
| Telephone/DSL Protection Details | 1 line |
| Cable (Coax) Protection | No |
| Network (Ethernet) Protection | No |
| PHYSICAL | |
| Unit Dimensions (HWD/in) | 2.5 x 6 x 3.5 |
| Unit Dimensions (HWD/cm) | 6.4 x 15.2 x 8.9 |
| Material of construction | Metal |
| Integrated keyhole mounting tabs | Metal end caps are fitted with keyhole mounting tabs for wallmount installation |
| Housing Color | Light Gray |
| Receptacle Color | Black |
| AC line cord color | Light Gray |
| Style | Strip |
| Outlets center to center measurement | Distance between horizontal outlets = 39.45mm; Distance between vertical outlets = 38.89mm |
| Keyhole slot center to center measurement | 131.90mm |
| SPECIAL FEATURES | |
| Appearance | Rugged all-metal corded strip format with high quality duplex receptacles |
| Right-Angle Plug | Yes |
| CERTIFICATIONS | |
| UL1449 3rd Edition (AC Suppression) | UL1449 |
| UL1283 (EMI Filter) | UL1283 |
| UL1363 (Power Tap) | UL1363 |
| UL497A (Communications) | UL497A |
| FCC Part 68 (Communications) | FCC Part 68 |
| cUL / CSA (Canada) | cUL |
| Industry Canada (Communications) | Industry Canada |
| Approvals | Exceeds IEEE 587 category A&B specifications |
